LED

RGB LED Strip 5m / 60 LEDs/m / 12V / WS2815 Addressable RGB flex strip with WS2815 chip, 12V design and 60 individually controllable LEDs per meter – reliable, WLED-compatible and available in two protection ratings. 60 LEDs/m, 1 LED per zone With 60 individually addressable LEDs per meter and a cut point every 16.67 mm, the strip is ideal for uniform effect lighting where every light point is controlled independently. 12V – practical operating voltage Compared to 5V strips, the 12V design allows longer cable runs without noticeable voltage drop – ideal for installations where the controller is not located directly at the strip. Variants IP20IP68Protection ratingIP20 – for indoor useIP68 – fully waterproof (silicone potting)Width10 mm12 mmHeight2 mm5 mmAmbient temperature0°C – 40°C−20°C – 40°CCoolingHeatsink required (min. 45 g/m)No heatsink requiredConnectorsC1-410 / C2-410O1-412IncludedStrip + 3M adhesive tapeStrip + 3M adhesive tape + 4 end caps + 20 mounting clips + 40 screws Specifications 60 LEDs/m, RGB, 1 LED per IC WS2815 chip, 12V DC, 8W/m 300 LEDs on 5m Cut point every 16.67 mm (1 SMD each) Beam angle 120° Max. length per power injection: 5m Dimmable via PWM Connection cable on both ends Adhesive tape: 3M 300LSE Rated lifetime: 57,000 h (L70|B50) Warranty: 2 years WLED Configuration The strip is fully WLED-compatible and is configured as follows: LED type: WS2812B / WS2815 Number of LEDs: 300 (for 5m) We recommend using our cod.m WLED Controller. Ideal for Room lighting and ambient light TV and media walls Indirect ceiling and profile lighting (IP20) Outdoor installations, wet areas, bathrooms (IP68) Smart Home / Home Assistant / WLED setups Usage Notes IP20: A heatsink profile of at least 45 g/m is mandatory – without adequate cooling, the strip's lifespan will be significantly reduced IP68: Any cuts must be resealed with sealant adhesive and end caps to maintain the protection rating Only cut at the copper pads – cutting elsewhere may damage traces Clean and degrease the surface before applying – once stuck down, do not remove

QuinLED FCOB RGBW COB LED Strip mit 896 LEDs/m, 160 adressierbaren Zonen und 3000K Warmweiß. 24V, WS2814, IP20, WLED-kompatibel FCOB RGBW LED Strip 5m / 160 Zones / 24V / WS2814 (IP20) The QuinLED Dig-COB-RGBW-896-160 is a top-tier addressable COB LED strip – with maximum zone density, true RGBW and 24V design. Built as a direct upgrade over common FCOB strips on the market. Why 160 zones + 896 LEDs/m RGBW is a genuine premium strip Many FCOB strips on the market work with around 80 zones over 5 meters and significantly lower LED density. This strip deliberately focuses on maximum resolution and light quality. Double the zone count With 160 individually addressable zones (32 zones/m, 3.125 cm each), effects can be rendered far smoother and more precisely than with conventional FCOB strips. Extreme LED density: 896 LEDs/m (RGBW) With 896 LEDs per meter and true RGBW configuration (224× Red, 224× Green, 224× Blue + 224× Warm White per meter), the result is an exceptionally uniform light output. This means: virtually seamless light surfaces with no visible structure extremely smooth color gradients without banding significantly higher detail in animations professional lighting quality even at static white True RGBW color mixing + high CRI The dedicated warm white channel (3000K) enables not just dynamic effects but also high-quality, living room-ready white light without RGB mixing. With a CRI of 93–94 (R9 ~60), the strip is equally suited for demanding ambient lighting applications. Specifications 896 LEDs/m (224× R, G, B, W) 160 addressable zones over 5m / 32 zones per meter / 3.125 cm zone pitch 24V (exclusively) RGBW, warm white 3000K, CRI 93–94 WS2814 chip, 4 kHz PWM frequency (low flicker) 12mm wide COB substrate, IP20 20AWG leads, incl. pre-assembled pigtails (JST SM) Max. power approx. 200W / 8.3A over 5m at full load Recommended in WLED: 43mA per zone, 160 zones WLED Configuration The strip is fully WLED-compatible (v0.14 and above) and is configured as follows: LED type: SK6812/WS2814 RGBW Color order: BGR + W&G swap Number of LEDs: 160 (for a full 5m strip) We recommend using a controller with a reliable 5V level-shifter on the data output – such as our cod.m WLED Controller. The strip is not compatible with 3.3V data signals. Ideal for high-quality ambient lighting TV and media walls indirect ceiling and profile lighting Smart Home / Home Assistant installations professional WLED effect setups Usage Notes Do not run the strip on the roll – heat dissipation is essential At power levels above 60W an aluminium profile for cooling is required, otherwise the strip's lifespan will be significantly reduced Do not bend around sharp corners Ensure no metal contacts the exposed electrical pads For 5m a single power injection is sufficient; for 10m dual-end injection is required Only cut on the copper pads – cutting anywhere else may damage traces ⚠ Warning: This LED strip is sensitive to short circuits. Make sure it is not installed in a way that allows two points on the front side to touch each other – this can permanently damage individual segments. Want to get started right away? Check out our WLED Controller RGBW/5m/160 Zones Premium Starterkit 24V/FCOB/WS2814 (WLAN) – including a pre-configured WLED Controller, Fused Capacitor Board and Mean Well power supply.
